The blades are synchronised to rotate in opposite directions and overlap each other by 75mm. This overlap, in combination with high blade tip speeds ensures that all vegetation is finely cut and evenly dispersed to leave a professional striped finish equivalent to that of a cylinder mower.
The gear-driven drive line delivers consistent cutting rates, even in heavy and wet conditions. The wings fold neatly to give a 2.5m transport width for safe transportation on public highways.
The Major TDR is produced from high-performance Strenx™ 700 MC structural steel. This material is stronger yet lighter than conventional mild steel. This results in reduced soil compaction and lower fuel costs without compromising the strength of the machine.
The machine is galvanised for the ultimate protection against corrosion, to safeguard your investment. For complete peace of mind, the Major TDR Mower is backed by a comprehensive, industry-leading 3-year warranty.
Features
- Full length rollers allows the unit to follow ground contours, prevent scalping and leaves a professional striped effect.
- Simple cutting height adjustment system. The cutting height can be adjusted from 10mm – 140mm for year-round mowing
- Premium quality components – Walterscheid wide angle PTO drive shaft
- Sealed internal roller bearings give protection against moisture and soil. Easy maintenance and replacement when required.
- The rear deck can be removed and used independently of the wings.
- The machine wings can be operated independently
- Axle mounted buffers absorb transport shocks, to protect the chassis and extend the service life of the machine.
- LED road lighting kit for safe use on roadways.
- BKT 300/65X12 turf tyres
- The braked axle ensures safe transportation when using public highways.
- Remote control unit allows operation of the unit, at the touch of a button, from the tractor cab.
- Axle mounted buffers absorb transport shocks, to protect the chassis and extend the service life of the machine.
- Covered by a comprehensive three-year warranty
Application
Parks and recreation
Polo fields
Racecourse
Sports fields & pitches
Specifications
| Model |
MJTDR-490 |
MJTDR-610 |
| Overall Width |
4.95m (16’3″) |
6.18m (20’3 ¼”) |
| Working Width |
4.90m (15’11”) |
6.10m (19’11 ½”) |
| Transport Width |
2.57m (8’5″) |
2.57m (8’5″) |
| Power (HP) |
65-100 HP |
75-120 HP |
| PTO rpm |
540 |
540 |
| Cutting Height |
10-140mm |
10-140mm |
| Rotors |
8 |
10 |
| Blades |
16 |
20 |
| Weight |
2335kg |
2550kg |
| Blade tip speed |
76m/s |
76m/s |
| Mowing Rates (Acres/hr at 7mph) |
12.15 |
15.23 |
