Retro-fit Universal Tanker Mounted Dribble Bar

The MAJOR Dribble Bar slurry applicator is designed to apply slurry to the soil surface as accurately as possible, while minimising grass contamination and ammonia emissions. This unit has 30 outlets spaced 260mm apart for even and precise distribution of liquid material in long and short grass. A high-strength steel is used in the manufacture of the MAJOR Dribble Bar and is hot dipped galvanised to increase durability and lifespan.



Features

  • Easily mounted onto the back door without welding or fabricating for simple retro-fitting
  • Choice of Vogelsang ExaCut or Mastek macerator. Both units distribute the slurry precisely and constantly
  • Can be used with the existing splashplate in place
  • Simple height adjustment allows the unit to be set according to tanker height making it adaptable to any tanker make or model.
  • Full lighting board is fitted as standard
  • Double self-aligning pivot hinge with easy access grease point on each wing
  • Hydraulic breakaway (optional extra)

Factory Fitted Dribble Bar

The MAJOR 10m and 12m Dribble Bars are designed to apply slurry to the soil surface as accurately as possible, while minimising grass contamination and ammonia emissions. These units have 40 or 48 outlets spaced evenly apart for precise distribution of liquid material in long and short grass.  A high-strength steel is used in the manufacture of the MAJOR Dribble Bar and is hot dipped galvanised to increase durability and lifespan.

Features

  • Factory fitted with a supporting buttress welded to the tank chassis
  • Vogelsang ExaCut macerator distributes slurry precisely and consistently
  • Can be used with the existing splashplate in place
  • Full lighting board is fitted as standard
  • Double self-aligning pivot hinge with easy access grease point on each wing
  • Hydraulic breakaway as standard

Application

Application Unit

Specifications

Model MJ91-750 MJ91-960 MJ91-1000 MJ91-1250
Working Width 7.5m (24’ 7”) 9.6m (31’ 6”) 10.1m (33’ 2”) 12.2m (40’)
Overall Width 7.73m (25’ 5”) 9.8m (33’ 2”) 10.25m (33’ 8”) 12.32m (40’ 5”)
Transport Width 2.2m (7’ 2”) 2.4m (8’) 2.2m (7’ 2”) 2.2m (7’ 2”)
Transport Height 2.8m (9’ 2”) 2.6m (8’ 10”) 2.4m (7’ 11”) 2.4m (7’ 11”)
Single/Double fold Single Double Double Double
Wing pivot 100° 180° & 85° 100° 100°
No. of outlets 30 38 40 48
Weight 420kg 870kg 900kg 1,020kg
Macerator Vogelsang or Mastek Vogelsang, Mastek or AOL Vogelsang or Mastek Vogelsang or Mastek
Hydraulic services required 2 double acting hydraulic spools 2 double acting hydraulic spools 2 double acting hydraulic spools 2 double acting hydraulic spools
Spacing 25cm 25cm 25cm 25cm
Bar/Spring System Bar Bar Bar Bar
Rear fill Yes Yes Yes Yes
Note Can be self retro fitted onto 20″ or 30″ back door Factory fitted. Suitable 2400 gallon tankers and up Factory fitted. Suitable 2400 gallon tankers and up Factory fitted. Suitable 2600 gallon tankers and up

If you'd like more information about a Major Dribble Bar, please call 01446 792786 or email Email.
