KRONE EasyCut B 870 – High-Output Rear Disc Mower Combination

The KRONE EasyCut B 870 is a high-performance rear-mounted disc mower combination designed for fast, efficient mowing across large grassland areas. When combined with a front-mounted mower, it provides an overall working width of approximately 8.31 m to 8.62 m, making it an excellent choice for farms and contractors looking to maximise daily mowing output.

Designed without a conditioner, the EasyCut B 870 combines a simple, robust construction with adjustable mower positioning and proven KRONE cutting technology. Despite its wide field coverage, the machine folds to just 2.99 m for road transport.

Key Features

Working Width up to 8.62 m

When operated with a suitable front mower, the EasyCut B 870 provides an overall working width of approximately:

• 8.31 m – 8.62 m

This provides excellent hectare output during busy forage harvesting periods.

Twin Rear Mower Units

The machine uses two 3.165 m mower units, providing wide coverage while allowing each unit to follow the ground effectively.

Adjustable Reach Arms

Two attachment positions allow the spacing between the rear mower units to be set at:

• 1,990 mm
• 2,300 mm

This helps maintain sufficient overlap when working around curves or across sloping ground.

Conditioner-Free Design

The EasyCut B 870 is designed without a conditioner, providing a straightforward and efficient mowing solution where conditioning is not required.

Compact Transport Width

Despite its large working width, the machine folds to approximately 2.99 m wide for convenient road transport.

Proven KRONE Cutterbar

Each mower unit uses proven KRONE disc mower technology to provide clean cutting and smooth crop flow across the full working width.

Performance & Operation

• Rear mower width: 2 × 3.165 m
• Combined working width: Approx. 8.31 – 8.62 m
• Transport width: Approx. 2.99 m
• Transport height: Approx. 3.70 m
• Mowing components: 5 discs + 2 drums per mower unit
• Power requirement: Approx. 120 hp
• Weight: Approx. 1,350 kg
• Linkage: Category II / III
• Conditioner: No

Adjustable Working Width

Flexible Mower Positioning

The adjustable rear mower position allows the operator to alter the overlap between the front and rear mowing units.

This is particularly useful when working:

• On slopes
• Around curved field boundaries
• Across uneven terrain
• In varying field conditions

Correct overlap helps prevent uncut strips and maintains a clean finish across the full mowing width.

Key Benefits

High Daily Output

Working widths up to 8.62 m allow large areas of grass to be mown quickly and efficiently.

Compact Road Transport

The machine folds to under 3 m wide, making transport between fields straightforward.

Excellent Overlap

Adjustable reach arms help maintain the correct overlap between front and rear mower units.

Simple Operation

The conditioner-free design provides a straightforward mowing setup with fewer components.

Clean Cutting Performance

Proven KRONE disc mower technology delivers consistent cutting across the full working width.

Ideal for Large Grassland Areas

Wide coverage makes the EasyCut B 870 particularly suitable for farms and contractors with significant areas to mow.

Applications

The KRONE EasyCut B 870 is ideal for:

• Grass silage mowing
• Hay production
• Large-scale forage harvesting
• Dairy and livestock farms
• High-output mowing
• Front and rear mower combinations
• Agricultural contractors

Why Choose the KRONE EasyCut B 870?

The KRONE EasyCut B 870 combines wide working widths, adjustable mower overlap and compact transport dimensions in a simple and robust rear mower combination. With an overall working width of up to 8.62 m when paired with a front mower, it provides the capacity required for efficient large-scale forage harvesting.

Enquire Now

For more information on the KRONE EasyCut B 870, including pricing, specifications, suitable front mower combinations and availability, contact KP Agri Ltd. Our team can help you choose the right KRONE mowing combination for your operation.
