DIECI AGRI MAX 75.10 S - GD

Dieci Agri Max 75.10 S - GD

The Agri Max 75.10 S – GD is a heavy-duty, high-capacity agricultural telehandler built for the most demanding large-scale operations. Designed to maximise load handling performance, it combines exceptional lifting strength with durability and operator comfort for continuous work cycles.

With a maximum lift capacity of 7,500 kg and a lifting height of 9.65 metres (9.5 m on wheels), the Agri Max 75.10 S is ideal for high bale stacking, bulk material handling and intensive yard operations. Powered by a 153 HP FPT Stage V engine, it delivers strong torque and reliable performance under sustained heavy loads.

A reinforced chassis and durable components ensure stability and long service life, while the hydrostatic transmission with variable displacement pump provides smooth, controlled movement during lifting and travel.

The Giugiaro-designed cab offers excellent visibility, high comfort levels and an intuitive onboard computer system for safe and efficient daily operation.

Key Specifications

Maximum capacity: 7,500 kg
Maximum lifting height: 9.65 m
Maximum power: 114 kW (153 HP)
Maximum speed: 40 km/h
Unladen weight: 13,500 kg
Engine: FPT 4,485 cm³, Stage V
Hydraulic pump capacity: 160 l/min
Maximum operating pressure: 26 MPa
Transmission: Hydrostatic with variable displacement pump
Standard tyres: 18x22.5
